135compact.com       110 cartridge ultra compact cameras       Lomography Diana Baby 110


The Lomography Diana Baby 110 is a very late camera for 110 pocket film
* (see below). It was released in the 2010's when Lomography re-introduced 110 film.

* 110 film was introduced by Kodak in 1972. The film sits in a cartridge, like Kodak's earlier 126 film, but is much smaller. A frame is 13mm 17mm, has one perforation per image to control film advance and 24 frames per cartridge (12 were also available). The film is protected by a backing paper like 120 film. The frame number is visible through a window at the back of the cartridge. The basic film is ordinary 16mm film which was already on the market, so it could be processed in existing machines. The small picture size made very small, pocketable cameras possible.

Kodak introduced with its 110 film a line of Kodak Pocket Instamatic cameras which were followed by cameras from other manufacturers. Most cameras were cheap point-and-shoot, but very sophisticated models were also made. Small digital cameras made 110 film obsolete. Bit by bit manufacturers
stopped making 110 format film (Fujifilm in 2009), but in 2012 (and 2019) Lomography made a large batch of 110 film, followed by other firms.


The camera is a simple entry model. It has a plastic body, but it features 2 interchangeable lenses.
Its main features are:

24mm and 12mm F8 interchangeable fixed focus plastic lenses, 24mm min. focus 1m, 12mm min focus 0.4m
Shutter 1/100s, B
Size 80x50x65,  Weight 75 gr. with film cartridge and 12mm lens
PC flash socket

jpg/110_diana_baby_110_IMG_5241.JPG
The whole set, camera, manual, 2 lenses, cap and 110 film unit.

jpg/110_diana_baby_110_IMG_5243.JPG
Camera with 12mm lens. Shutter button next to the lens. The shutter button is unusually thight when the film back is attached. It releases the film advance mechanically. So you don't waste photos by advancing film without haveng taken a photo.

jpg/110_diana_baby_110_IMG_5244.JPG
Bottom. Slider for shutter setting, N=1/100 and B. Slider to detach the back.


jpg/110_diana_baby_110_IMG_5245.JPG
Top view. PC flash socket.


jpg/110_diana_baby_110_IMG_5246.JPG
Camera back. Viewer.

jpg/110_diana_baby_110_IMG_5247.JPG
Size comparison. It's realy tiny.

jpg/110_diana_baby_110_IMG_5248.JPG
Camera with 24mm lens.

jpg/110_diana_baby_110_IMG_5249.JPG
If you want to detach the back, you have to push the slider against its spring and get the 2 parts separated. You may have to introduce a fingernail into the seam and force a bit.

jpg/110_diana_baby_110_IMG_5250.JPG
The back detached. This back has no technical function, it's only there to look cute.

jpg/110_diana_baby_110_IMG_5251.JPG
The film back. It looks like a part made from a 110 micro camera.

jpg/110_diana_baby_110_IMG_5252.JPG
Film back attached to the camera.

jpg/110_diana_baby_110_IMG_5253.JPG
Seen from the back. The cartridge is held by the transparent piece of plastic which is hinged.

jpg/110_diana_baby_110_IMG_5254.JPG
Ready to receive the cartridge. Obviously they adapted a standard film plane to their square format.

jpg/110_diana_baby_110_IMG_5256.JPG
Cartridge inserted. The camera looks less elegant than with the fake back.

jpg/110_diana_baby_110_IMG_5257.JPG
Ready to go out.

jpg/110_diana_baby_110_IMG_5259.JPG
Seen from the front.

jpg/110_diana_baby_110_IMG_5260.JPG
Seen from the back.

jpg/110_diana_baby_110_IMG_5264.JPG
Seen from top.

jpg/110_diana_baby_110_IMG_5265.JPG
And from the bottom.

jpg/110_diana_baby_110_IMG_5261.JPG
Lens in detached position. You have to turn it clockwise to lock.

jpg/110_diana_baby_110_IMG_5262.JPG
Lens locked. Turn anti-clockwise to release. On my camera it's extremely thight, you need a pipe wrench (and a piece of cloth) to unlock.

This camera is very easy to use and very light.
It has no manual settings except N or B shutter. You only have to frame. After taking a picture, you have to turn the wheel for film advance. There is no shutter cocking, so multiple exposure is possible. Putting a film is easy as well, you drop the film into the compartment, lock it, advance to the first frame and that's it.

It's a simple point and shoot camera with no settings. No focussing, no aperture choice and only one shutter speed. So you have to choose your film according to the weather, 100 or 200 ISO for sunny weather and ISO 400 for dull weather. You better use flash for interiors. It wastes film as it only makes square photos without giving you more exposures. The most interesting thing about this camera is its 12mm lens. As far as I know there is no other 110 camera that wide. The finder is made for the 12mm lens. There is a tiny frame to indicate the 24mm framing, but it's nearly unusuable, it's just a guess. As nearly all Lomo stuff this is just a fun camera.
